Configuration
22 UDC2300 Universal Digital Controller User Manual 4/00
3.3 Timer Set Up Group
Introduction
The Timer Set Up group allows you to configure a time-out period and to select
the timer start by either the keyboard (RUN/HOLD key) or Alarm 2. The optional
digital input can also be configured to start the timer. The timer display is
selectable as either “time remaining” (see TREM) or “elapsed time” (see ET).
Alarm 1 is activated at the end of the time-out period. When the timer is enabled,
it has exclusive control of the alarm 1 relay—any previous alarm 1 configuration
is ignored. At time-out, the timer is ready to be activated again by whatever
action has been configured.
Function Prompts
Table 3-2 TIMER Group (Numeric Code 100) Function Prompts
Prompt Selection or Range of Setting
English Numeric
Code
Description
Numeric
Code
English
Factory
Setting
TIMER
101 Enable or
Disable Timer
0
1
DIS
ENAB
DIS
PERIOD
102 Time-out Period 0:00 to 99:59
Select length of time in
Hours and Minutes, or
Minutes and Seconds.
0:01
START
103 Timer Function
Start
0
1
KEY (Run/Hold key)
AL2 (Alarm 2)
KEY
L DISP
104 Timer Display 0
1
TREM (time remaining)
ET (elapsed time)
TREM
RESET
105 Timer Reset
Control
0
1
KEY (Run/Hold key)
AL1 (Alarm 1 or Key)
KEY
INCRMT
106 Timer Count
Increment
0
1
MIN (Counts HR/MIN)
SEC (Counts MIN/SEC)
MIN
