Honeywell UDC 2300 User Manual

Operation
4/00 UDC2300 Universal Digital Controller User Manual 51
4.12 Setting a Failsafe Output Value for Restart After a Power Loss
Introduction
If the power to the controller fails and power is reapplied, the controller goes
through the power up tests, then goes to a user configured FAILSAFE OUTPUT
VALUE.
Set a Failsafe Value
Table 4-11 Procedure for Setting a Failsafe Value
Step Operation Press Result
1 Select Control
Set-up Group
SET UP
Until you see:
Upper Display = SET
Lower Display = CONTRL
2 Select Failsafe
Function
Prompt
FUNCTION
You will see:
Upper Display = (range)
within the range of the Output 0 to 100 for all output
types except 3 Position Step
3 Position Step
0 = motor goes to closed position
100 = motor goes to open position
Lower Display = FAILSF
3 Select a value [▲] [▼] To select a Failsafe output value in the upper display
4 Return to
Normal Display
DISPLAY
At power up, the output will go to the value set.
