Configuration
4/00 UDC2300 Universal Digital Controller User Manual 27
3.6 Accutune Set Up Group
Introduction
Accutune II automatically calculates GAIN, RATE, and RESET TIME (PID)
tuning constants for your control loop. When initiated on demand, the Accutune
algorithm measures a process step response and automatically generates the
PID tuning constants needed for no overshoot on your process.
Fuzzy Overshoot Suppression, when enabled, will suppress or eliminate any
overshoot that may occur as a result of the existing tuning parameters, as the PV
approaches the setpoint.
Function Prompts
Table 3-5 ATUNE Group (Numeric Code 400) Function Prompts
Prompt Selection or Range of Setting
English Numeric
Code
Description
Numeric
Code
English
Factory
Setting
FUZZY
401 Fuzzy
Overshoot
Suppression
0
1
DIS
ENAB
DIS
TUNE
402 Demand
Tuning
0
1
DIS
TUNE
TUNE
AT ERR
403 Accutune Error
Codes (Read
Only)
0
3
4
5
NONE
IDFL
ABRT
RUN
- - -
To Next Page
