Honeywell UDC 2300 User Manual

Configuration
26 UDC2300 Universal Digital Controller User Manual 4/00
Prompt Selection or Range of Setting
English Numeric
Code
Description
Numeric
Code
English
Factory
Setting
ENDSEG 309 End Segment
Number
2
4
6
8
10
12
2 to 12 (always end in a
soak segment 2, 4, …12)
SOK 2
SOK4
SOK6
SOK8
SOK10
SOK12
0
RPUNIT 310 Engineering units for
Ramp Segments
0
1
2
TIME (hours:minutes)
EU-M (Rate EU/Minute)
EU-H (Rate EU/Hour)
TIME
RECYCL 311 Number of Program
Recycles
0 to 99 recycles - - -
SOKDEV 312 Guaranteed Soak
Deviation Value
0 to 99
0 = No Soak
- - -
PG END 313 Program
Termination State
0
1
LAST (Hold at last SP)
FSAF (Manual
mode/Failsafe)
- - -
STATE 314 Program State at
Program End
0
1
DIS
HOLD
DIS
ToBEGN 315 Reset Program to
the Beginning
0
1
DIS
KEY (Keyboard)
DIS
PVSTRT 316 Program starts at
PV value
0
1
DIS
ENAB
DIS
SGx RP
SG1
SG3
SG5
SG7
SG9
SG11
317
320
323
326
329
332
Segment Ramp or
Rate Time
x = 1 through 11
0-99hours:0-59minutes
Engineering Units/minute
or
Engineering Units /hour
- - -
SGx SP
SG2
SG4
SG6
SG8
SG10
SG12
318
321
324
327
330
333
Segment Soak
Setpoint Value
x = 2 through 12
Enter a Value within the
Setpoint Limits
- - -
SGx TI
SG2
SG4
SG6
SG8
SG10
SG12
319
322
325
328
331
334
Segment Soak
Duration
x = 2 through 12
0-99 Hours: 0-59 Minutes - - -
