Installation
4/00 UDC2300 Universal Digital Controller User Manual 3
2 Installation
2.1 Overview
Introduction
Installation of the UDC 2300 consists of mounting and wiring the controller
according to the instructions given in this section. Read the pre-installation
information, check the model number interpretation (Appendix B), and become
familiar with your model selections, then proceed with installation.
2.2 Preliminary Checks
Introduction
Before you install the controller, remove the chassis and make any preliminary
checks necessary that are listed in Table 2-1. Figure 2-1 shows the locations for
jumper placements.
Table 2-1 Preliminary Checks
Check
Number
Preliminary Check Description
1
Input I Jumper Placement Check the internal jumper for INPUT 1 to make
sure it is set for the correct input type. The jumper
is located at position S101 on the printed wiring
board. Figure 2-1 shows the location of the jumper
and position selections.
2
Optional Input 2 (RSP)
Jumper Placement
Check the internal jumper for INPUT 2 to make
sure it is set for the correct input type. The jumper
is located at position S201 on the printed wiring
board. Figure 2-1 shows the location of the jumper
and position selections.
3
Control Relay 1 and Current
Output
Check the internal jumper (W101) for CONTROL.
The relay is shipped as N.O. (Normally Open).
Figure 2-1 shows the location of the jumper and
position selections.
See Table 2-2 for Control Relay contact
information.
To Next Page
