Honeywell UDC 2300 User Manual

Configuration
4/00 UDC2300 Universal Digital Controller User Manual 25
3.5 SP Ramp Set Up Group
Introduction
A single setpoint ramp [SPRAMP] can be configured to occur between the
current local setpoint and a final local setpoint over a time interval of from 1 to
255 minutes.
SPRATE lets you configure a specific rate of change for any local setpoint
change.
You can also configure a 12-segment program from a Ramp/Soak profile.
You can start and stop the ramp/program using the RUN/HOLD key.
PV Hot Start is standard and means that at power up, the setpoint is set to the
current PV value and the Ramp or Rate or Program then starts from this value.
Function Prompts
Table 3-4 SPRAMP Group (Numeric Code 300) Function Prompts
Prompt Selection or Range of Setting
English Numeric
Code
Description
Numeric
Code
English
Factory
Setting
SP RAMP
301 Single Setpoint
Ramp
Rate and Program
must be disabled
0
1
DIS
ENAB
DIS
TI MIN
301 Single Setpoint
Ramp Time
0 to 255 Minutes
3
FINLSP
302 Setpoint Ramp Final
Setpoint
Enter a value within the
setpoint limits
1000
SPRATE
304 Setpoint Rate
Ramp and Program
must be disabled
0
1
DIS
ENAB
DIS
EUHRUP
305 Rate Up 0 to 9999 in Engineering
units per hour
0
EUHRDN
306 Rate Down 0 to 9999 in Engineering
units per hour
0
SPPROG
307 Setpoint Ramp/Soak
Programming
Rate and Ramp
must be disabled
0
1
DIS
ENAB
DIS
STRSEG
308 Start Segment
Number
1 to 11 - - -
Table continued next page
