Configuration
32 UDC2300 Universal Digital Controller User Manual 4/00
3.10 Control Set Up Group
Introduction
The functions listed in this group deal with how the controller will control the
process including: Number of Tuning Parameter Sets, Setpoint Source, Tracking,
Power-up Recall, Setpoint Limits, Output Direction and Limits, Deadband, and
Hysteresis.
Function Prompts
Table 3-9 CONTRL Group (Numeric Code 800) Function Prompts
Prompt Selection or Range of Setting
English Numeric
Code
Description
Numeric
Code
English
Factory
Setting
PIDSET
801 Number of Tuning
Parameter Sets
0
1
2
3
ONE
2KBD (Keyboard)
2 PR (PV switch)
2 SP (SP switch)
ONE
SW VAL
802 Automatic Switchover
Value
Value in engineering units
within PV or SP range limits
0.00
LSP’S
803 Local Setpoint Source 0
1
ONE
TWO
ONE
RSPSRC
804 Remote Setpoint
Source
0
1
NONE
INP2
NONE
SP TRK
805 Setpoint Tracking 0
1
2
NONE
PROC (LSP tracks PV–
manual)
RSP (LSP tracks RSP–auto)
NONE
PWR UP
806 Power Up Controller
Mode Recall
0
1
2
3
4
MAN (Manual/LSP/Failsafe)
ALSP (Auto/last LSP)
ARSP (Auto/last RSP)
AMSP (Last mode/last SP)
AMLS (Last mode/last LSP)
ALSP
PWROUT
807 TPSC (Three Position
Step Control) Output
Start-up Mode
0
1
LAST (Last output)
FSAF (Failsafe output)
LAST
SP Hi
808 Setpoint High Limit 0 to 100 % of the PV range 2400
SP Lo
809 Setpoint Low Limit 0 to 100 % of the PV range 0
ACTION
810 Control Output
Direction
0
1
DIR
REV
REV
Table continued next page
