Configuration
4/00 UDC2300 Universal Digital Controller User Manual 33
Table 3-9 CONTRL Group (Numeric Code 800) Function Prompts, continued
Prompt Selection or Range of Setting
English Numeric
Code
Description
Numeric
Code
English
Factory
Setting
OUT Hi
811 High Output
Limit
-5 to 105 % of Output
(Current)
0.0 to 100.0 % of Output
(Relay)
100
OUT Lo
812 Low Output
Limit
-5 to 105 % of Output
(Current)
0.0 to 100.0 % of Output
(Relay)
0
D BAND
813 Deadband -5 to 25.0 % (Time Duplex)
0.5 to 5.0 % (3 position step)
2.0
HYST
814 Hysteresis
(Output Relay
Only)
0.0 to 100.0 % of PV 0.5
FAILSF
815
816
Failsafe Output
Value
0
1
0 to 100 %
For 3 Position Step
0 (Closed position)
100 (Open position)
0.0
FSMODE
817 Failsafe Mode 0
1
No L (Mode does not clear
once unit goes to FS Output)
LACH (Unit goes to manual
and FS output)
NO_L
PBorGN
818 Proportional
Band Units
0
1
GAIN
PB
GAIN
MINRPM
819 Reset Units 0
1
MIN
RPM
MIN
