Configuration
4/00 UDC2300 Universal Digital Controller User Manual 31
3.9 Input 2 Set Up Group
Function Prompts
Table 3-8 INPUT2 Group (Numeric Code 700) Function Prompts
Prompt Selection or Range of Setting
English Numeric
Code
Description
Numeric
Code
English
Factory
Setting
IN2TYP
701 Input 2 Type 0
25
26
29
30
34
DIS
0-20 (mA)
4-20 (mA)
0-5 (Volts)
1-5 (Volts)
0-2 (Volts)
1-5V
Numeric English Numeric English
XMITR2
702 Transmitter
Characterization for
Input 2
0
1
2
3
4
5
6
7
8
9
10
11
12
B
E H
E L
J H
J L
K H
K L
NNMH
NNML
N90H
N90L
NIC
R
13
14
15
16
17
18
19
20
21
22
23
24
25
S
T H
T L
W H
W L
100H
100L
200
500
RADH
RADI
LIN
SrT
LIN
Numeric
Code
English
IN2 HI
703 Input 2 High Range
Value
−999 to 9999 floating in
engineering units
2400
IN2 LO
704 Input 2 Low Range
Value
−999 to 9999 floating in
engineering units
0
RATIO2
705 Ratio on Input 2 -20.0 to 20.0 1.00
BIAS 2
706 Bias on Input 2
-999 to 9999
0.0
FILTR2
707 Filter for Input 2
0 to 120 seconds
0 = No Filter
1.0
