102 Getting Started HP 81110/04A Quick Start
Getting Started
Examples
# Set the period to 12.5 ns.
:PULSe:PERiod 12.5NS
# Set the output voltage to high level 2.5 Volts and low level to 0.0 Volts
# for both channels.
:VOLTage1:HIGH 2.5V
:VOLTage1:LOW 0V
:VOLTage2:HIGH 2.5V
:VOLTage2:LOW 0V
# Enable the output 1 and the output 2.
:OUTPut1 ON
:OUTPut2 ON
# To enable the complement output 1 and the complement output 2
# (only HP 81110A with HP 81112A 10V/330 MHz outputs installed)
# the following commands have to be included:
:OUTPut1:COMPlement ON
:OUTPut2:COMPlement ON
