36 Introduction HP 81110/04A Quick Start
Introduction
General Information
NOTE: Please refer to the Reference Guide, part number 81110-91011,
for the command reference list.
The HP 81110A compared to the HP 81104A has better accuracy, up to
330 MHz clock rate, 800 ps typical edges at up to 3.8 V, and a timing
auto calibration.
Upgrade Capability
It is possible to upgrade the instruments with a second channel if only
one channel was originally ordered. There are two output channels avail-
able for the HP 81110A. The second channel that is installed must be the
same as channel one.
NOTE: Do not mix the output channels for the HP 81110A.
Table 1: Mainframe / Output Module Combinations
Mainframe Module Description
HP 81104A HP 81105A 10V/ max. 80 MHz Output Channel
HP 81110A HP 81111A
HP 81112A
10V/ max. 165 MHz Output Channel
3.8V/ max. 330 MHz Output Channel
