This quick start guide helps you to quickly install the instrument, to get
familiar with the features, the user interface and give the set up informa-
tion for some real-world signal examples which can easily be used by
varying only some parameter values.
The information is valid for HP 81104A and HP 81110A. Where
required the differences are explicitly mentioned. Possible configura-
tions are:
Output Module for HP 81104A Mainframe:
Output Modules for HP 81110A Mainframe:
As standard the instruments are equipped with one output channel, so,
some of the described features will not be available.
Module Description Max Quantity
HP 81105A 10V/ max.80 MHz Output Channel 2
Module Description Max Quantity
HP 81111A 10V/ max. 165 MHz Output Channel 2
Module Description Max Quantity
HP 81112A 3.8V/ max. 330 MHz Output Channel 2
