18 Installation & Safety Requirements HP 81110/04A User’s Guide
Installation & Safety Requirements
Initial Inspection
Options and Accessories:
Options
Rear Panel Connectors Option UN2
All inputs and outputs are at the rear
panel.
Second Channel HP 81105A 10V/80 MHz for
mainframe HP 81104A
HP 81111A 10V/165 MHz or
HP 81112A 3.8V/330 MHz for
mainframe HP 81110A
1 MB SRAM Memory Card Option UFH
(HP part numer 0950-3880)
Figure 2 Standard Instrument’s Rear Panel
Figure 3 Rear Panel Connectors when Option UN2 is installed
