HP 81110A - Device Command List for the Data Stream Signal

HP 81110/04A Quick Start Getting Started 89
Getting Started
Examples
Device Command List for the Data Stream Signal
• If you want to include this Data Stream Signal in your program use
the following command lines in boldface font. The comment lines
starting with a # are not required.
• The commands are listed with the channel specifier for channel 1, if
there is a second channel installed and you want to program it with a
similar signal, use the same commands and replace 1 by 2 for the
second channel, where required.
# Reset the instrument to start from a defined, default status.
*RST
# Switch off the automatic display update to increase programming
# speed.
:DISPlay OFF
# Set the instrument to pattern mode and select NRZ data output format
# for output 1.
:DIGital:PATTern ON
:DIGital:SIGNal1:FORMat NRZ
# For example the command to set NRZ data format for the optional
# second channel is:
# :DIGital:SIGNal2:FORMat NRZ
# Define a pattern length of 24 bit and program the pattern:
# ‘111001110011001001010010’.
:TRIGger:COUNt 24
