108 Getting Started HP 81110/04A Quick Start
Getting Started
Examples
:PULSe:WIDTh1 100NS
:PULSe:TRANsition1 3NS
:PULSe:WIDTh2 100NS
:PULSe:DOUBle2 ON
:PULSe:DOUBle2:DELay 250NS
:PULSe:TRANsition2 3NS
# Set the output amplitude to 2 Volts and the offset to 0.0 Volts for both
# channels.
:VOLTage 2V
:VOLTage2 2V
# Enable the output 1 and the output 2.
:OUTPut ON
:OUTPut2 ON
# To enable the complement output 1 and the complement output 2
# (only HP 81110A with HP 81112A 3.8V/330MHz Outputs installed)
# the following commands have to be included:
:OUTPut:COMPlement ON
:OUTPut2:COMPlement ON
