50 Introduction HP 81110/04A Quick Start
Introduction
Setting Timing Parameter Formats and Values
NOTE: For HP 81110A with HP 81112A, 3.8V/330 MHz Output channels
installed you can select between two fixed transitions, 800 ps or
1.6 ns. The trailing edge is always the same as the leading edge.
5 Trailing Edge Parameter - =
Lead E, Absolute,% of Width
6 Output Status - ON, OFF
Can also be varied in the |LEVELS| screen.
NOTE: If only one channel is installed, then all signal parameters are
grouped in an OUTPUT screen. If you prefer the signal parameter
grouping for each Output, then please refer to “Changing
Configuration” on page 62. Refer also to “Output/Output 1 and
Output 2 Parameter Grouping” on page 64.
7 Differential Output Status -
ON, OFF
Can also be varied in the |LEVELS| screen.
NOTE: Differential Outputs are available with HP 81110A with
HP 81112A, 3.8V/330 MHz Output channels installed.
Switch the output status to ON to avoid parameter conflicts, please refer
to “Internal Error Check” on page 52.
