56 Introduction HP 81110/04A Quick Start
Introduction
Editing Pattern
the memory with a divided clock pattern.- Fill 0, Fill 1, Invert,
First Bit, Last Bit, Ins Bit, Del Bit, Clock
÷
N
,
PRBS 2n-1.
NOTE: Most of the block editing functions apply from (or at) the current Addr
of the bit-editing window to the Last bit in the pattern
For further information on the block editing functions, please refer to the
HP 81110A / HP 81104A Reference Guide (p/n 81110-91010) Chapter 1,
Pattern Screen.
5 Data Output Format - RZ, NRZ
Can also be varied in the |MODE/TRG| screen.
