HP 81110/04A Quick Start Getting Started 85
Getting Started
Examples
NOTE: For HP 81110A with HP 81112A 3.8V/330 MHz Output channel
installed the transitions can be selected either 800 ps or 1.6 ns.
Leading and trailing edge are equal.
# Set the amplitude to 3.3 Volts, the offset to 1.65 Volts.
:VOLTage1 3.3V
:VOLTage1:OFFSet 1.65V
# Enable the output 1 and the complement output 1 (HP 81110A
# with HP 81112A 3.8V/330 MHz output channel installed, only).
:OUTPut1 ON
:OUTPut1:COMPlement ON
