96 Getting Started HP 81110/04A Quick Start
Getting Started
Examples
:DIGital:PATTern:DATA2 #1800001000
# Set the frequency to 30 MHz, and a delay of 10 ns for output 2, the
# transition times for output 1 to 5ns to have same transition time
# shape as the added second channel, see comment in step 5.
:FREQuency 30MHZ
:PULSe:TRANsition1 5NS
:PULSe:DELay2 10NS
# Set the output voltage to high level 1.0 Volts and low level to 0.0 Volts
# for both channels. Then select channel addition mode, see manual
# step 4.
:VOLTage1:HIGH 1V
:VOLTage1:LOW 0V
:VOLTage2:HIGH 1V
:VOLTage2:LOW 0V
:CHANnel:MATH PLUS
# Enable the output 1 and the output 2.
:OUTPut1 ON
:OUTPut2 ON
