Figures
1-1. The Tunable Laser Source Front Panel .... .... .... 1-2
1-2. Starting Screen for the 8168F . . . . . . . . . . . . . . . . . 1-3
1-3. \Secure: Unlock Instrument" Screen ............. 1-4
1-4. \Secure" Screen . . . . . . . . . . . . . . . . . . . . . . . 1-4
1-5. A Summary of the Help Hard- and Softkeys . . . . . . . . . . 1-5
1-6. The Help Topics Menu .................... 1-5
1-7. Connecting the Instruments for the Sample Session .. .... 1-9
1-8. Tunable Laser Source Display after Setting Up W
avelength and
Power . . . . . . . . . . . . . . . . . . . . . . . . . .
1-10
1-9. Tunable Laser Source Display during Setting Up for the
Wavelength Sweep .................... 1-11
2-1. A Summary of the additional Output Power Softkeys for the
Attenuator Option .................... 2-2
2-2. Setting the Wavelength Directly .. .... .... .... . 2-2
2-3. Setting a Relative Wavelength .. .... .... .... .. 2-3
2-4. Setting Up for a Wavelength Sweep . . . . . . . . . . . . . . 2-4
2-5. The Parameters for a Wavelength Sweep .... .... ... 2-5
2-6. Performing a Manual Sweep .... .... .... .... . 2-7
2-7. Setting the Output Power of a CW Signal ........... 2-8
2-8. The Modulated Signal .................... 2-11
2-9. Setting the Output Power of an Internally Modulated Signal .. 2-11
2-10. External Modulation and Output Power . . . . . . . . . . . . 2-12
2-11. Setting the Output Power of an Externally Modulated Signal . . 2-13
2-12. Setting the Output Power of a Coherence Controlled Signal . . . 2-14
2-13. The Coherence Control Uncalibrated Power and the Maximum
Power Level ....................... 2-14
3-1. User Setting Number 1 . . . . . . . . . . . . . . . . . . . . 3-1
3-2. Summary of the Setting Hard- and Softkeys . . . . . . . . . . 3-2
3-3. The System Screen . . . . . . . . . . . . . . . . . . . . . . 3-3
3-4. Summary of the System Hard- and Softkeys . . . . . . . . . . 3-3
3-5. Auxiliary Functions (8167A, 8168D/E) . . . . . . . . . . . . . 3-6
3-6. Auxiliary Functions (8168F) ................. 3-6
