2
Note
If coherence control is enabled, and the uncal power level
cannot be exceeded for the full wavelength range chosen, the
wavelength range is reduced as necessary.
Executing an Automatic Sweep
You can perform an automatic sweep if you press
N
NNNNNNNNNNNNN
Auto
after setting up the
sweep parameters, or if you press
N
NNNNNNNNNNNNN
Cont
during a manual sweep.
Press
NNNNNNNNNNNNNNNNN
Pause
to interrupt the sweep. The instrument switches to a manual
sweep (see \Performing a Manual Sweep").
Press
N
NNNNNNNNNNNNN
Stop
to end the sweep.
Example
Set the instrument to sweep the range 1495nm to 1555nm,
three times, in 1nm steps, stopping for half a second at
each wavelength, at the highest power level available at all
wavelengths.
1.
Press
4
WAVELENGTH
5
and then
NNNNNNNNNNNNNNNNNNNNNNN
-Sweep
.
2. Make sure you are at the
start
parameter.
3. Type in 1495 and then
4
ENTER
5
, to set the start wavelength.
4. Type in 1555 and then
4
ENTER
5
, to set the stop wavelength.
5. Type in 1 and then
4
ENTER
5
, to set the step size.
6. Type in 0.5 and then
4
ENTER
5
, to set the dwell time.
7. Type in 3 and then
4
ENTER
5
, to set the number of cycles.
8.
Press
NNNNNNNNNNNNNNNNNNNNNN
Pmax
!
P
, to set the power.
9. Enable the optical output, if necessary.
10.
Press
N
NNNNNNNNNNNNN
Auto
, to run the application.
Performing a Manual Sweep
You can perform a manual sweep if you press
NNNNNNNNNNNNNNNNNNNN
Manual
after setting up the
sweep parameters, or if you press
NNNNNNNNNNNNNNNNN
Pause
during an automatic sweep. During a
manual sweep the display looks as follows:
2-6 Setting Wavelength and Power
