Installation 26
3.
Slide the front end of the rail to the rack front column. When fully seated, the rack rail will lock into
place.
4. Repeat the procedure for the right rack rail.
Installing the enclosure into the rack
The empty enclosure with the rear cage installed weighs 58.6 kg (129 lb). When the enclosure is
disassembled, the empty enclosure without the rear cage installed weighs 35.5 kg (78 lb). The empty rear
cage weighs 23.2 kg (51 lb).
WARNING: Always use at least two people to lift an enclosure into the rack. If the enclosure is
being loaded into the rack above chest level, a third person must assist with aligning the enclosure
with the rails while the other two people support the weight of the enclosure.
To install the enclosure into the rack:
1. At the front of the rack, lift and align the enclosure guiding fins with the guiding groove in the rack rails.
IMPORTANT: Be sure that the guiding fins on the enclosure seat properly in the guiding groove
on the rack rail.
