Cabling and powering up the enclosure
Cabling the enclosure
After all system hardware is installed, cable the components. See the HP ProLiant BladeSystem c-Class Site
Planning Guide on the Documentation CD or the HP website (http://www.hp.com) for additional cabling
and site planning requirements.
WARNING: To reduce the risk of electric shock or injury due to high-current electrical energy, be
sure that all power is completely disconnected at the source before beginning any power
connections to the power bus bars or power bus box.
WARNING:
Be sure that all circuit breakers are locked in the off position before connecting any
power components.
To cable the system:
1. Connect the Onboard Administrator modules.
2. Connect the network cables to the interconnect modules. See the documentation that ships with the
interconnect modules, or the HP ProLiant BladeSystem c-Class Site Planning Guide on the
Documentation CD or the HP website (http://www.hp.com/go/bizsupport).
3. Connect to the AC or DC power source in your facility and power up the enclosure ("Powering up the
enclosure" on page 59).
Onboard Administrator cabling
