HP BladeSystem c7000 - Accessing local media devices

Installation 41
4.
Connect a USB keyboard to the second USB connector.
Item Description
1
Monitor
2
USB mouse
3
HP c-Class Blade SUV cable
4
Server blade
5
Video connector
6
USB keyboard
Accessing local media devices
Use a USB hub when connecting a USB diskette drive and/or USB CD-ROM drive to the blade. The USB hub
provides additional connections.
Use the following configuration when configuring a blade or loading software updates and patches from a
USB CD/DVD-ROM or a USB diskette drive.
1. Connect the HP c-Class Blade SUV cable to the blade.
2. Connect the video connector to a monitor.
3. Connect a USB hub to one USB connector.
4. Connect the following to the USB hub:
o USB CD/DVD-ROM drive
o USB keyboard
o USB mouse
