Installation 39
3.
Tilt the shelf at an angle with the left edge up. Align the three tabs on the left edge of the shelf with the
openings in the enclosure, and then push the device bay shelf up.
CAUTION: Be sure that all five tabs (three on the left side of the shelf and two on the right side of
the shelf) are fully engaged before sliding the shelf forward to complete the installation. Failure to
do so can cause damage to server blade connectors during installation.
4. Align the two tabs on the right edge of the device bay shelf with the openings, and slide the device bay
shelf into the enclosure to lock it.

HP BladeSystem c7000 Specifications

General

Form Factor	10U
Number of Bays	16
Redundant Power	Yes
Redundant Fans	Yes
Maximum Blade Servers	16 half-height or 8 full-height
Operating Temperature	10° to 35°C (50° to 95°F)
Power Supplies	Up to 6
Cooling Fans	10
Management	Onboard Administrator
Interconnect Modules	Up to 8
Networking Options	Ethernet, Fibre Channel, InfiniBand
Compatibility	HP ProLiant and Integrity server blades
Relative Humidity	10% to 90% (non-condensing)
