6–26 361288-003 Service Reference Guide, dc7100
Removal and Replacement Procedures - Convertible Minitower (CMT) Chassis
10. Install the drive by sliding it into the appropriate drive bay on the front of the chassis. The
drivelock automatically secures the drive in the bay.
Ä
CAUTION: Make sure the guide screws line up with the guide slots in the drive cage. The use of
unnecessary force when installing any drive into the drive bay may result in damage to the drive.
11. When installing an optical drive, the default audio solution is digital audio. No separate
audio cable is required for Windows XP applications.
12. Connect the data and power cables on the to the drive.
✎
Refer to Chapter 4, “Serial and Parallel ATA Drive Guidelines and Features” for information on
attaching the cabling to get optimum performance.
13. Replace the front bezel (Section 6.6).
14. Replace the computer access panel (Section 6.5)
15. If you normally lock the Smart Cover Lock, use Computer Setup to relock the lock and
enable the Smart Cover Sensor (Section
6.2).

HP Compaq dc7100 DT Specifications

General

Processor Speed	Up to 3.8 GHz
Chipset	Intel 915G
Memory	Up to 4 GB DDR2 SDRAM
Operating System	Windows XP Professional
Form Factor	Desktop
Processor	Intel Pentium 4
Storage	40 GB to 160 GB SATA
Graphics	ATI Radeon X300 SE
Optical Drive	DVD-ROM
Audio	Integrated audio
Network	Integrated Gigabit Ethernet
Expansion Slots	1 PCI Express x16
Ports	1 Parallel, 1 Serial, 2 PS/2, 1 VGA
