HP Compaq dc7100 DT User Manual

Service Reference Guide, dc7100 361288-003 6–39
Removal and Replacement Procedures - Convertible Minitower (CMT) Chassis
6.22 Power Supply
Å
WARNING: Voltage is always present on the system board when the computer is plugged into an
active AC outlet. To avoid possible personal injury and damage to the equipment the power cord should
be disconnected from the computer and/or the AC outlet before opening the computer.
1. Prepare the computer for disassembly (Section 6.1).
1. Remove the computer access panel (Section 6.5).
2. Disconnect all power cables from the mass storage devices and from the system board.
3. Remove the four screws that connect the power supply to the chassis 1.
4. Slide the power supply toward the front of the computer, then lift it out of the computer 2.
To install the power supply, reverse the removal procedure.

HP Compaq dc7100 DT Specifications

General

Processor Speed	Up to 3.8 GHz
Chipset	Intel 915G
Memory	Up to 4 GB DDR2 SDRAM
Operating System	Windows XP Professional
Form Factor	Desktop
Processor	Intel Pentium 4
Storage	40 GB to 160 GB SATA
Graphics	ATI Radeon X300 SE
Optical Drive	DVD-ROM
Audio	Integrated audio
Network	Integrated Gigabit Ethernet
Expansion Slots	1 PCI Express x16
Ports	1 Parallel, 1 Serial, 2 PS/2, 1 VGA
