7–24 361288-003 Service Reference Guide, dc7100
Removal and Replacement Procedures— Small Form Factor (SFF) Chassis
15. Reinstall the expansion card cage by aligning the cage with the guide rails on the backwall.
Press down firmly on the cage to secure it in place on the backwall. Be sure the riser card in
the cage is properly seated in the PCI expansion slot on the system board.
Complete the reassembly of the computer.
