Service Reference Guide, dc7100 361288-003 7–33
Removal and Replacement Procedures— Small Form Factor (SFF) Chassis
✎
When replacing the hard drive, transfer the four screws from the old drive to the new one. The
screws take the place of drive rails. You will need a Torx T-15 screwdriver to remove and
re-install the guide screws. HP has provided four extra 6-32 standard guide screws on the front of
the chassis, under the computer cover. The 6-32 standard guide screws are silver.
✎
If you replaced the primary hard drive, insert the Restore Plus! CD to restore the operating
system, software drivers, and any software applications that were preinstalled on the computer.
Follow the instructions in the guide included with the Restore Plus! CD. When the restore
process has completed, reinstall any personal files that you backed up before replacing the hard
drive.

HP Compaq dc7100 DT Specifications

General

Processor Speed	Up to 3.8 GHz
Chipset	Intel 915G
Memory	Up to 4 GB DDR2 SDRAM
Operating System	Windows XP Professional
Form Factor	Desktop
Processor	Intel Pentium 4
Storage	40 GB to 160 GB SATA
Graphics	ATI Radeon X300 SE
Optical Drive	DVD-ROM
Audio	Integrated audio
Network	Integrated Gigabit Ethernet
Expansion Slots	1 PCI Express x16
Ports	1 Parallel, 1 Serial, 2 PS/2, 1 VGA
