7–56 361288-003 Service Reference Guide, dc7100
Removal and Replacement Procedures— Small Form Factor (SFF) Chassis
19. Install the new PCI riser card cage assembly on the new backwall by aligning the cage with
the guide rails on the backwall. Press down firmly on the cage to secure it in place on the
backwall. Be sure the riser card in the cage is properly seated in the PCI expansion slot on
the system board.
20. Slide the drive cage back into its operating position and lock it in place. Be sure to use proper
cable handling and placement precautions.
Ä
CAUTION: Cables are very sensitive. Overbending, creasing, or pinching can damage cables.

HP Compaq dc7100 DT Specifications

General

Processor Speed	Up to 3.8 GHz
Chipset	Intel 915G
Memory	Up to 4 GB DDR2 SDRAM
Operating System	Windows XP Professional
Form Factor	Desktop
Processor	Intel Pentium 4
Storage	40 GB to 160 GB SATA
Graphics	ATI Radeon X300 SE
Optical Drive	DVD-ROM
Audio	Integrated audio
Network	Integrated Gigabit Ethernet
Expansion Slots	1 PCI Express x16
Ports	1 Parallel, 1 Serial, 2 PS/2, 1 VGA
