HP Compaq dc7100 DT User Manual

Service Reference Guide, dc7100 361288-003 D–21
Power LED flashes Red five
times, once every second,
followed by a two second
pause, and the computer
beeps five times. Beeps
continue for five iterations
after which the LED flashes
will continue until the
problem is resolved.
Memory is installed
incorrectly or is bad.
1. Reseat DIMMs.
2. Replace DIMMs one at a time to
isolate the faulty module.
3. Replace third-party memory
with HP memory.
4. Replace the system board.
Power LED flashes Red six
times, once every second,
followed by a two second
pause, and the computer
beeps six times. Beeps
continue for five iterations
after which the LED flashes
will continue until the
problem is resolved.
Video card is not seated
properly or is bad, or
system board is bad.
For systems with a graphics card:
1. Reseat the graphics card. Power
on the system.
2. Replace the graphics card.
3. Replace the system board.
For systems with integrated
graphics, replace the system board.
Power LED flashes Red ten
times, once every second,
followed by a two second
pause, and the computer
beeps ten times. Beeps
continue for five iterations
after which the LED flashes
will continue until the
problem is resolved
Bad option card. 1. Check each option card by
removing the cards one at time
(if multiple cards), then power
on the system to see if fault goes
away.
2. Once bad card is identified,
remove and replace bad option
card.
3. Replace the system board.
Solving Hardware Installation Problems (Continued)
Problem Cause Solution

HP Compaq dc7100 DT Specifications

General

Processor Speed	Up to 3.8 GHz
Chipset	Intel 915G
Memory	Up to 4 GB DDR2 SDRAM
Operating System	Windows XP Professional
Form Factor	Desktop
Processor	Intel Pentium 4
Storage	40 GB to 160 GB SATA
Graphics	ATI Radeon X300 SE
Optical Drive	DVD-ROM
Audio	Integrated audio
Network	Integrated Gigabit Ethernet
Expansion Slots	1 PCI Express x16
Ports	1 Parallel, 1 Serial, 2 PS/2, 1 VGA
