HP Elite x2 G8 User Manual

Table 7-16 Issues, possible causes, and xes (continued)
Items Procedures
Troubleshooting steps
1. Check for any blink patterns. Count the number of blinks in a sequence, followed by a
pause for a few seconds.
2. See status, blinking lights, and error message (7. Status lights, blinking light codes,
troubleshooting lights, and POST error messages on page 76) for corrective actions.
3. If internal hardware components (such as memory, hard drive) have been recently
added, a component may not be connected properly. Remove and reseat new
components (10. Reseat cables and connections on page 80) one at a time.
Note Because the display might not be functional, lights are used to indicate an error.
Diagnostic error messages
Use the information in the table to help you understand diagnostic error messages.
Table 7-17 Issues, possible causes, and xes
Items Procedures
Symptoms
● Computer has power
● POST error message displays
(Windows logo has not yet
appeared)
Possible causes
Diagnostic error messages indicate a problem. There may be a problem with the instruction
being sent from the BIOS to a hardware component (for example, keyboard failures), or
incompatible hardware. Can usually be resolved by installing updated rmware for the
component.
Troubleshooting steps
1. See 7. Status lights, blinking light codes, troubleshooting lights, and POST error
messages on page 76 for corrective actions. An example of a POST error message
might be "Boot Device Not Found."
2. If there is power, you might be able to access BIOS. Reset BIOS to its default condition.
(9. Soft reset (Default Settings) on page 79)
3. Restore hardware to its original condition (for example, bootable solid-state drive
instead of hard drive).
4. Reseat suspected components and verify connection.
5. Test suspected components using HP PC Hardware Diagnostics (UEFI) tool.
Note An Error Message means that the system has nished BIOS hardware validation and is ready
to launch the Startup Menu. To access the Startup Menu for further options, press the esc
key while restarting the computer.
BIOS password
Use the information in the table to troubleshoot BIOS password issues.
Table 7-18
Issues, possible causes, and xes
Items Procedures
Symptoms Possible causes
Diagnostic error messages 93

HP Elite x2 G8 Specifications

General

Form factor	Convertible (Detachable)
Product type	Hybrid (2-in-1)
Product color	Silver
Country of origin	China
Market positioning	Premium
Original brand name	HP
HD type	3K2K
Color gamut	72 %
Display surface	Gloss
RGB color space	NTSC
Display diagonal	13 \
Anti-glare screen	Always gives an optimal view, even in direct sunlight.
Display brightness	450 cd/m²
Display resolution	3000 x 2000 pixels
Display diagonal (metric)	33 cm
Numeric keypad	No
Pointing device	Clickpad
Internal memory	16 GB
Memory clock speed	4266 MHz
Memory form factor	On-board
Internal memory type	LPDDR4x-SDRAM
HP segment	Business
HP speaker type	HP Dual Speakers
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	NVMe, PCI Express
Storage media	SSD
SSD memory type	TLC
Total storage capacity	512 GB
Number of SSDs installed	1
Repairability index	8.4
Battery weight	190 g
Battery capacity	47 Wh
Number of battery cells	2
Discrete graphics card model	Not available
On-board graphics card model	Intel Iris Xe Graphics
Front camera HD type	Full HD
Antenna type	2x2
Wi-Fi standards	Wi-Fi 6 (802.11ax)
Bluetooth version	5.0
WLAN controller model	Intel Wi-Fi 6 AX201
WLAN controller manufacturer	Intel
Charging port type	USB Type-C
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
Processor cache	8 MB
Processor cores	4
Processor family	Intel® Core™ i5
Processor threads	8
Configurable TDP-up	28 W
Processor frequency	- GHz
Processor cache type	L3
Configurable TDP-down	12 W
Processor boost frequency	4.4 GHz
Configurable TDP-up frequency	2.6 GHz
Configurable TDP-down frequency	1.1 GHz
AC adapter power	65 W
Operating system installed	Windows 11 Pro
Package depth	483 mm
Package width	69 mm
Package height	305 mm

Weight and Dimensions

Depth	221.9 mm
Height	14.2 mm
Weight	1170 g
Depth (tablet mode)	215.8 mm
Width (tablet mode)	289.3 mm
Height (tablet mode)	8.8 mm
Weight (tablet mode)	820 g
