Removal and replacement procedures for
Customer Self-Repair parts
5
This chapter provides removal and replacement procedures for Customer Self-Repair parts.
NOTE: The Customer Self-Repair program is not available in all locations. Installing a part that is not
supported by the Customer Self-Repair program can void your warranty. Check your warranty to determine
whether Customer Self-Repair is supported in your location.
Component replacement procedures
To remove and replace computer components, use these procedures.
NOTE: Details about your computer, including model, serial number, product key, and length of warranty,
are on the service tag at the bottom of your computer.
NOTE: HP continually improves and changes product parts. For complete and current information about
supported parts for your computer, go to http://partsurfer.hp.com, select your country or region, and then
follow the on-screen instructions.
You must remove, replace, or loosen as many as 44 screws when you service Customer Self-Repair parts.
Make special note of each screw size and location during removal and replacement.
Preparation for disassembly
To prepare to disassemble the computer, use these steps.
See Removal and replacement procedures preliminary requirements on page 31 for initial safety procedures.
1. Turn o the computer. If you are unsure whether the computer is o or in Hibernation, turn the computer
on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
Kickstand
To remove the kickstand, use this procedure and illustration.
Table 5-1
Kickstand description and part number
Description Spare part number
Kickstand L67409-001
Before removing the kickstand, prepare the computer for disassembly (see Preparation for disassembly on
page 40).
Remove the kickstand:
40
Chapter 5 Removal and replacement procedures for Customer Self-Repair parts
