Product description1
This table provides detailed product information.
Table 1-1 Product components and their descriptions
Category Description
Product Name
HP Elite x2 G8 Tablet
Processors Intel® Core™ processors, quad core
Intel Core i7-1185 G7 (1.9 GHz, turbo up to 4.6 GHz, 16 MB SmartCache, 15 W)
Intel Core i7-1185 G7 (1.8 GHz, turbo up to 4.6 GHz, 16 MB SmartCache, 15 W)
Intel Core i7-1165 G7 (1.8 GHz, turbo up to 4.6 GHz, 16 MB SmartCache, 15 W)
Intel Core i5-1145 G7 (1.6 GHz, turbo up to 4.1 GHz, 8 MB SmartCache, 15 W)
Intel Core i5-1145 G7 (1.6 GHz, turbo up to 3.9 GHz, 16 MB SmartCache, 15 W)
Intel Core i5-1145 G7 (1.6 GHz, turbo up to 3.9 GHz, 8 MB SmartCache, 15 W)
Intel Core i5-1135 G7 (1.6 GHz, turbo up to 3.9 GHz, 16 MB SmartCache, 15 W)
Intel Core i5-1135 G7 (1.6 GHz, turbo up to 3.9 GHz, 16 MB SmartCache, 15 W)
Intel Core i3-1125 G4 (1.6 GHz, turbo up to 3.9 GHz, 8 MB SmartCache, 15 W)
Intel Core i3-1115 G4 (1.6 GHz, turbo up to 3.9 GHz, 8 MB SmartCache, 15 W)
Display 33.02 cm (13.00 in), White Light Emitting Diode (WLED), Ultra Wide Viewing Angle (UWVA), Embedded Display
Port (eDP) 1.4 + Panel Self Refresh (PSR), 72% of the National Television Standards Committee (NTSC),
ultraslim, touch screen
Widescreen Ultra Extended Graphics Array (WUXGA+) (1920 × 1280), antiglare, privacy, 1000 nits
3k × 2k (3000 × 2000), BrightView, 450 nits
Memory Memory soldered onto system board, not upgradable, not removable
Supports dual-channel memory
Supports the following congurations:
8 GB (4 × 2)
16 GB (8 × 2)
Primary storage PCIe, NVMe, M.2 2280 solid-state drives
2 TB, PCIe, TLC, 3 × 4
1 TB, PCIe, TLC, 3 × 4, NVMe
512 GB, PCIe + 32 GB with 3D Xpoint
512 GB, PCIe, TLC
512 GB, PCIe, value
512 GB, PCIe, self-encrypting drive (SED), Opal 2, TLC, 3 × 4
256 GB, self-encrypting drive (SED), Opal 2, TLC, 3 × 4
256 GB, PCIe, NVMe
256 GB, PCIe, TLC
Product description 1

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP Elite x2 G8 and is the answer not in the manual?

HP Elite x2 G8 Specifications

General IconGeneral
Form factorConvertible (Detachable)
Product typeHybrid (2-in-1)
Product colorSilver
Country of originChina
Market positioningPremium
Original brand nameHP
HD type3K2K
Color gamut72 %
Display surfaceGloss
RGB color spaceNTSC
Display diagonal13 \
Anti-glare screenAlways gives an optimal view, even in direct sunlight.
Display brightness450 cd/m²
Display resolution3000 x 2000 pixels
Display diagonal (metric)33 cm
Numeric keypadNo
Pointing deviceClickpad
Internal memory16 GB
Memory clock speed4266 MHz
Memory form factorOn-board
Internal memory typeLPDDR4x-SDRAM
HP segmentBusiness
HP speaker typeHP Dual Speakers
SSD capacityThe Solid State Drive's storage capacity in Gigabytes.
SSD interfaceNVMe, PCI Express
Storage mediaSSD
SSD memory typeTLC
Total storage capacity512 GB
Number of SSDs installed1
Repairability index8.4
Battery weight190 g
Battery capacity47 Wh
Number of battery cells2
Discrete graphics card modelNot available
On-board graphics card modelIntel Iris Xe Graphics
Front camera HD typeFull HD
Antenna type2x2
Wi-Fi standardsWi-Fi 6 (802.11ax)
Bluetooth version5.0
WLAN controller modelIntel Wi-Fi 6 AX201
WLAN controller manufacturerIntel
Charging port typeUSB Type-C
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity0
Processor cache8 MB
Processor cores4
Processor familyIntel® Core™ i5
Processor threads8
Configurable TDP-up28 W
Processor frequency- GHz
Processor cache typeL3
Configurable TDP-down12 W
Processor boost frequency4.4 GHz
Configurable TDP-up frequency2.6 GHz
Configurable TDP-down frequency1.1 GHz
AC adapter power65 W
Operating system installedWindows 11 Pro
Package depth483 mm
Package width69 mm
Package height305 mm
Weight and Dimensions IconWeight and Dimensions
Depth221.9 mm
Height14.2 mm
Weight1170 g
Depth (tablet mode)215.8 mm
Width (tablet mode)289.3 mm
Height (tablet mode)8.8 mm
Weight (tablet mode)820 g
