HP Elite x2 G8

4. If you need to remove the microphone cable from the camera module, remove the screw (2), slide the
privacy cover o the module (3), and then rotate the microphone module (4) to remove it from the
bottom of the camera module (5).
Reverse this procedure to install the camera module, IR LED cable, and microphone cable.
Speakers with antennas
To remove the speakers with antennas, use this procedure and illustration.
Table 6-9
Speakers and antennas description and part number
Description Spare part number
Antennas, WWAN L67432-001
Antennas, WWAN M51641-001
Speakers with WLAN antennas M51638-001
Speakers with WWAN antennas M51639-001
Speakers with GPS antennas L67429-001
Speakers with WWAN antennas for HP INT XMM 7360 LTE w/GPS M.2 L70670-005
Before removing the speakers, follow these steps:
1. Prepare the computer for disassembly (see Preparation for disassembly on page 40).
2. Remove the display assembly (see Display panel on page 42).
Speakers with antennas
55
