Hardware options installation 72
— 24-pin power cable connecting to system board
4 LFF hot-plug configuration
8 SFF hot-plug configuration
CAUTION: To prevent improper cooling and thermal damage, do not operate the server
unless all bays are populated with either a component or a blank.
11. Install the system air baffle (on page 22).
12. If removed, install the PCI air baffle ("Install the PCI air baffle" on page 20).
13. Install the access panel (on page 18).
14. Connect the power cords to the power supplies.
15. Connect the power cords to the AC power source.
16. Employ best practices to route and manage the power cords and other cables in the server rear
panel.
17. Power up the server.
