EN
Reference Diagrams
7-83
PS106 Fuser paper delivery sensor 2 Sensor and flag located on Fuser
assembly.
PS501 Fuser paper delivery sensor 1 Sensor located on Engine Controller.
Flags on Engine Controller Board and
Fusing Assembly.
PS701 Duplex pickup paper sensor
(Duplexer)
Sensor and flag located in Duplexer.
PS703 Reversed paper sensor (Duplexer) Sensor and flag located in Duplexer.
PS902 Envelope multiple feed sensor
(Envelope Feeder)
Sensor and flag located in Envelope
Feeder.
Table 7-35. Paper Sensors in Figure 7-18 (continued)
