7-82 Troubleshooting
EN
Figure 7-17 Paper Path with the Envelope Feeder
Figure 7-18 Paper Sensors and the Paper Path
Table 7-35. Paper Sensors in Figure 7-18
PS102 Pre-feed sensor Sensor and flag located on
Registration/Feed Sensor Assembly.
PS103 Top of page sensor Sensor and flag located on
Registration/Feed Sensor Assembly.
