Expanding the OmniBook
Connecting External Devices
56 User’s Handbook
For information about connecting to serial devices, USB devices, audio devices, and
infrared devices, see the section “Connecting External Devices” in the online Reference
Guide.
To connect an external monitor
You can connect a VGA, SVGA, XGA, or SXGA monitor to your OmniBook—or
UXGA for a computer with “900 B” after the serial number. A 12-inch internal display
supports standard SVGA mode (800 by 600 pixels), and a 13-inch display supports XGA
mode (1024 by 768 pixels).
1. Press the blue power button for one second to suspend the OmniBook.
2. Connect the monitor cable to the monitor, then to the monitor port on the back of the
OmniBook.
3. Connect the monitor to a power source and turn it on.
4. Press the blue power button to turn on the OmniBook.
5. If the external monitor has a different resolution from the internal display, adjust the
display properties (My Computer, Control Panel, Display, Settings).
Hint
Turn on the monitor before turning on the computer. This makes plug-and-play features
on the monitor available to the computer.
To enable the built-in and external displays
• For a temporary change, press Fn+F5 to cycle through the display options (Internal,
External, Both).
• For a permanent change in which display is active, change the Video Display Device
setting in the BIOS Setup utility (see below).
• For a display connected to a video adapter in a docking system, the docking display is
automatically selected when it is detected. To change this behavior, change the
Primary Video Adapter setting in the BIOS Setup utility (see below).
See “To run the BIOS Setup utility” on page 66.
