13. Disconnect the small cable from the POGO board (1), and slide the power connector from the slot (2).
To install the power supply, reverse the removal procedures.
NOTE: When connecting the antennas cables, connect the cable labeled “1” to the MAIN connector on the
module and the cable labeled “2” to the AUX connector on the module.
ENWW Power supply 101
