Separating the computer from the column
You must remove the computer from the column before you can service the column. The computer is secured
to the column using four Torx screws. One power cable connects the column to the computer as well.
1. Prepare the computer for disassembly (see
Preparing to disassemble the column on page 77).
2. Remove the rear covers from the computer (see
Removing the rear covers from the computer
on page 78).
3. Remove the two right screws that secure the computer to the column.
80 Chapter 5 Removal and Replacement Procedures – Column ENWW
