HP Sprout Maintenance & Service Guide

●
On select models, if you want to recover the computer's original factory partitioning and content, you
can choose the System Recovery option from the HP Recovery partition or use the HP Recovery media
that you have created. For more information, see
Recovering using HP Recovery Manager on page 131.
If you have not already created recovery media, see
Creating HP Recovery media on page 129.
●
On select models, if you have replaced the hard drive, you can use the Factory Reset option of HP
Recovery media to restore the factory image to the replacement drive. For more information, see
Recovering using HP Recovery Manager on page 131.
Recovering using HP Recovery Manager
HP Recovery Manager software allows you to recover the computer to its original factory state by using the
HP Recovery media that you created or by using the HP Recovery partition. If you have not already created
recovery media, see
Creating HP Recovery media on page 129.
From the Start screen, type recovery, select Recovery Manager, select System Recovery, and then follow
the on-screen instructions.
What you need to know
●
HP Recovery Manager recovers only software that was installed at the factory. For software not
provided with the computer, you must either download the software from the manufacturer's website
or reinstall the software from the media provided by the manufacturer.
IMPORTANT: Recovery through HP Recovery Manager should be used as a final attempt to correct
computer issues.
●
HP Recovery media must be used if the computer hard drive fails. If you have not already created
recovery media, see
Creating HP Recovery media on page 129.
●
If the HP Recovery media does not work, you can obtain recovery media for your system from support.
See the Worldwide Telephone Numbers booklet included with the computer. You can also find contact
information from the HP website. Go to
http://www.hp.com/support, select your country or region, and
follow the on-screen instructions.
IMPORTANT: HP Recovery Manager does not automatically provide backups of your personal data. Before
beginning recovery, back up any personal data you want to retain.
Using the HP Recovery partition
The HP Recovery partition allows you to perform a system recovery without the need for recovery discs or a
recovery USB flash drive. This type of recovery can be used only if the hard drive is still working.
To start HP Recovery Manager from the HP Recovery partition:
1. From the Start screen, type recovery, select Recovery Manager, and then select HP Recovery
Environment.
2. Select Troubleshoot from the boot options menu.
3. Select Recovery Manager, and then follow the on-screen instructions.
Using HP Recovery media to recover
You can use HP Recovery media to recover the original system. This method can be used if your system does
not have an HP Recovery partition or if the hard drive is not working properly.
ENWW Restore and recover 131

HP Sprout Specifications

General

Full HD	Yes
Screen shape	Flat
Display diagonal	23 \
Touch technology	Multi-touch
Native aspect ratio	16:9
Detachable display	No
Storage drive interface	Serial ATA
Tcase	71.35 °C
Bus type	DMI
Stepping	C0
Processor code	SR1QM
Processor cache	8 MB
Processor cores	4
Processor model	i7-4790S
System bus rate	5 GT/s
Processor family	Intel® Core™ i7
Processor series	Intel Core i7-4700 Desktop series
Processor socket	LGA 1150 (Socket H3)
Processor threads	8
Processor codename	Haswell
Number of QPI links	0
Processor frequency	3.2 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	4 GHz
Processor operating modes	64-bit
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	65 W
Maximum number of PCI Express lanes	16
Memory types supported by processor	DDR3-SDRAM
Memory channels supported by processor	Dual
Memory clock speeds supported by processor	1333, 1600 MHz
Memory bandwidth supported by processor (max)	25.6 GB/s
Maximum internal memory supported by processor	32 GB
Memory slots	2
Internal memory	8 GB
Memory slots type	SO-DIMM
Memory clock speed	1600 MHz
Internal memory type	DDR3L-SDRAM
Maximum internal memory	16 GB
Memory layout (slots x size)	2 x 4 GB
HDD speed	5400 RPM
HDD interface	SATA
Storage media	Hybrid-HDD
Hybrid-HDD cache type	Flash
Total storage capacity	1000 GB
Compatible memory cards	SD, SDHC, SDXC
Number of storage drives installed	1
On-board graphics card ID	0x412
Discrete graphics card model	NVIDIA® GeForce® GT 745A
On-board graphics card model	Intel® HD Graphics 4600
Discrete graphics card memory	2048 GB
Discrete graphics memory type	GDDR3
On-board graphics card family	Intel® HD Graphics
Maximum on-board graphics card memory	1.7 GB
On-board graphics card base frequency	350 MHz
On-board graphics card DirectX version	11.1
On-board graphics card dynamic frequency (max)	1200 MHz
Number of displays supported (on-board graphics)	3
Audio system	DTS Studio Sound
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	4.0
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Operating system installed	Windows 8.1
Scalability	1S
Processor ARK ID	80808
Intel TSX-NI version	0.00
Processor package size	37.5 x 37.5 mm
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Thermal solution specification	PCG 2013C
Intel® Smart Response Technology	-
Intel Identity Protection Technology version	1.00
Product color	Silver
Country of origin	China
Product type	All-in-One PC
Motherboard chipset	Intel® H97
Total megapixels	1 MP
AC adapter power	350 W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (with stand)	577 mm
Width (with stand)	594 mm
Height (with stand)	605 mm
Weight (with stand)	15280 g
