Computer boards
Item Description
(1) System board
(2) Power button board
(3) Ambient light sensor board
(4) Microphone module
(5) Right I/O board
(6) Left I/O board
(7) Webcam module
(8) Converter board
WLAN module (HP WLAN 802.11 a/b/g/n + Bluetooth 4.0; not illustrated)
4-GB memory module (SODIMM; PC3-12800, 1666-MHz; not illustrated)
Intel Core i7-4790S processor (3.2 GHz, 8 MB cache, 65 W) (includes replacement thermal material; not illustrated)
12 Chapter 2 Illustrated parts catalog ENWW
