System board
Description
System board for use in models without Windows 8
System board for use in models with Windows 8 Standard
System board for use in models with Windows 8 Professional
To remove the system board:
1. Prepare the computer for disassembly (see
Preparing to disassemble the computer on page 25).
2. Remove the rear covers (see
Removing the rear covers from the computer on page 26).
3. Remove the hard drive (see
Hard drive on page 28).
4. Remove the memory modules (see
Memory on page 30).
5. Remove the wireless USB dongle (see
Wireless USB dongle on page 32).
6. Separate the computer from the column (see
Separating the computer from the column on page 35).
7. Remove the system board cover (see
System board cover on page 47).
8. Remove the heat sink (see
Heat sink on page 60).
9. Remove the fan (see
Fan assembly on page 63).
10. Remove the processor (see
Processor on page 62).
11. Remove the WLAN module (see
WLAN module on page 49).
68 Chapter 4 Removal and Replacement Procedures – Computer ENWW
