4. Battery 2 status LEDs1. Battery 1 status LEDs
5. Enclosure status LEDs2. Fan 1 status LEDs
6. Front UID push button3. Fan 2 status LEDs
Figure 9 Controller enclosure (front bezel)
8. Fan 1 normal operation LED1. Rack-mounting thumbscrew
9. Fan 1 fault LED2. Enclosure product number and serial number
10. Fan 23. World Wide Number (WWN)
11. Battery 24. Battery 1
12. Enclosure status LEDs5. Battery normal operation LED
13. Front UID push button6. Battery fault LED
7. Fan 1
Figure 10 Controller enclosure (front view with bezel removed)
EVA4400 hardware22
