Figure 12 shows the back view of the HSV300–S controller enclosure
Management module
The web-based operator control panel (WOCP) provides a direct interface to the management module
within each controller. From the WOCP you can display storage system status and configuration
information, shut down the storage system, and manage the password. For tasks to perform with the
WOCP, see the WOCP online help.
The WOCP provides two levels of administrator access and an interface for firmware updates to the
management module. For additional details about the WOCP, see the WOCP online help.
Controller status indicators
The status indicators display the operational status of the controller. The function of each indicator is
described in Table 7. During initial setup, the status indicators might not be fully operational.
Each port on the rear of the controller has an associated status indicator located directly above it.
Table 5 lists the port and its status description for the HSV300. Table 6 lists the port and its status
descriptions for the HSV300–S.
Table 5 HSV300 controller port status indicators
DescriptionPort
Green — Normal operation
Amber — No signal detected
Off — No SFP
1
detected or the Direct Connect WOCP setting is incorrect
Fibre Channel host ports
Green — Normal operation
Amber — No signal detected or the controller has failed the port
Off — No SFP
1
detected
Fibre Channel device ports
1
On copper Fibre Channel cables, the SFP is integrated into the cable connector.
Table 6 HSV300-S controller port status indicators
DescriptionPort
Green on — Normal operation or loopback port
Green flashing — Normal online I/O activity
Amber on — Faulted port, disabled due to diagnostics or Portdisable
command
Amber flashing — Port with no synchronization, receiving light but not
yet online or segmented port
Off — No SFP
1
, no cable, no license detected.
Fibre Channel switch ports
Green — Normal operation
Amber — No signal detected or the controller has failed the port
Off — No SFP
1
detected
Fibre Channel device ports
EVA4400 hardware24
