HP StorageWorks User Manual

106 External Storage XP for the XP12000/XP10000
Relationship between serial numbers in the Device list on the LU Operation pane and TagmaStore
AMS and TagmaStore WMS subsystem models
When the external disk array is a TagmaStore AMS or TagmaStore WMS subsystem, you can identify the
subsystem model from the serial number displayed in the Serial column in the Device list on the LU
Operation pane.
Table 17 shows the relationship between serial numbers displayed in the Serial column and subsystem
models.
NOTE: In serial numbers, X is an arbitrary number or character.
Relationship between the WWN of the port on the TagmaStore AMS or TagmaStore WMS
subsystem and the controller
When the external disk array is a TagmaStore AMS or TagmaStore WMS subsystem, you can identify the
controller (controller 0 or controller 1) from the port’s WWN.
Table 18 shows the relationship between the port’s WWN and the controller.
Table 17 Relationship between serial numbers and subsystem models (TagmaStore AMS and TagmaStore
WMS subsystems)
Storage subsystem Displayed serial number Model
AMS 77XXXXXX AMS 1000
75XXXXXX AMS 500
73XXXXXX AMS 200
WMS 71XXXXXX WMS 100
Table 18 Relationship between ports’ WWNs and controllers (TagmaStore AMS and TagmaStore WMS
subsystems)
Model Controller Port’s WWN
AMS 200
WMS 100
Controller 0 XXXXXXXXXXXXXXX0
Controller 1 XXXXXXXXXXXXXXX1
AMS 500 Controller 0 XXXXXXXXXXXXXXX0
XXXXXXXXXXXXXXX1
Controller 1 XXXXXXXXXXXXXXX2
XXXXXXXXXXXXXXX3
AMS 1000 Controller 0 XXXXXXXXXXXXXXX0
XXXXXXXXXXXXXXX1
XXXXXXXXXXXXXXX2
XXXXXXXXXXXXXXX3
Controller 1 XXXXXXXXXXXXXXX4
XXXXXXXXXXXXXXX5
XXXXXXXXXXXXXXX6
XXXXXXXXXXXXXXX7
