HPE FlexFabric 5950 Series User Manual

151
Step Command Remarks
2. Create a static CRLSP.
• Configure the ingress node:
static-cr-lsp ingress lsp-name
{ nexthop ip-address |
outgoing-interface interface-type
interface-number } out-label
out-label-value [ bandwidth [ ct0 |
ct1 | ct2 | ct3 ] bandwidth-value ]
• Configure a transit node:
static-cr-lsp transit lsp-name
in-label in-label-value { nexthop
ip-address | outgoing-interface
interface-type interface-number }
out-label out-label-value
[ bandwidth [ ct0 | ct1 | ct2 | ct3 ]
bandwidth-value ]
• Configure the egress node:
static-cr-lsp egress lsp-name
in-label in-label-value
Use one command according
to the position of a device on
the network.
By default, no static CRLSPs
exist.
Do not configure the next hop
address as a local public IP
address when configuring the
static CRLSP on the ingress
node or a transit node.
You do not need to execute the
static-cr-lsp egress
command on the egress node
if the outgoing label configured
on the penultimate hop of the
static CRLSP is 0 or 3.
71B
Displaying static CRLSPs
Execute display commands in any view.
Task Command
Display static CRLSP information.
display mpls static-cr-lsp
[
lsp-name
lsp-name ] [
verbose
]
72B
Static CRLSP configuration example
206BNetwork requirements
Switch A, Switch B, and Switch C run IS-IS.
Establish an MPLS TE tunnel over a static CRLSP from Switch A to Switch C to transmit data
between the two IP networks. The required bandwidth for the tunnel is 2000 kbps.
The maximum bandwidth for MPLS TE traffic is 10000 kbps, and the maximum reservable
bandwidth is 5000 kbps.
