HPE FlexFabric 5950 Series

221
Task Command
instance. [
statistics
|
verbose
]
Display information about a specified
or all VPN instances.
display ip vpn-instance
[
instance-name
vpn-instance-name ]
Display the FIB of a VPN instance.
display fib vpn-instance
vpn-instance-name
Display FIB entries that match the
specified destination IP address in
the specified VPN instance.
display fib vpn-instance
vpn-instance-name ip-address
[ mask-length | mask ]
Display BGP VPNv4 peer group
information.
display bgp
[
instance
instance-name ]
group vpnv4
[
vpn-instance
vpn-instance-name ] [
group-name
group-name ]
Display BGP VPNv4 peer
information.
display bgp
[
instance
instance-name ]
peer vpnv4
[
vpn-instance
vpn-instance-name ] [ ipv4-address mask-length | { ipv4-address |
group-name
group-name }
log-info
| [ ipv4-address ]
verbose
]
Display BGP VPNv4 routes.
display bgp
[
instance
instance-name ]
routing-table vpnv4
[ [
route-distinguisher
route-distinguisher ] [ ipv4-address
[ { mask-length | mask } [
longest-match
] ] | ipv4-address
[ mask-length | mask ]
advertise-info
|
as-path-acl
as-path-acl-number |
community-list
{ { basic-community-list-number | comm-list-name } [
whole-match
]
| adv-community-list-number } ] | [
vpn-instance
vpn-instance-name ]
peer
ipv4-address {
advertised-routes
|
received-routes
} [ ipv4-address [ mask-length | mask ] |
statistics
]
|
statistics
]
Display incoming labels for BGP
IPv4 unicast routes.
display bgp
[
instance
instance-name ]
routing-table ipv4
[
unicast
] [
vpn-instance
vpn-instance-name ]
inlabel
Display outgoing labels for BGP IPv4
unicast routes.
display bgp
[
instance
instance-name ]
routing-table ipv4
[
unicast
] [
vpn-instance
vpn-instance-name ]
outlabel
Display incoming labels for BGP
VPNv4 routes.
display bgp
[
instance
instance-name ]
routing-table vpnv4
inlabel
Display outgoing labels for BGP
VPNv4 routes.
display bgp
[
instance
instance-name ]
routing-table vpnv4
outlabel
Display BGP VPNv4 address family
update group information.
display bgp
[
instance
instance-name ]
update-group vpnv4
[
vpn-instance
vpn-instance-name ] [ ipv4-address ]
Display OSPF sham link information.
display ospf
[ process-id ]
sham-link
[
area
area-id ]
For more information about the display ip routing-table, display bgp group vpnv4, display bgp
peer vpnv4, and display bgp update-group vpnv4 commands, see Layer 3—IP Routing
Command Reference.
102B
MPLS L3VPN configuration examples
245BConfiguring basic MPLS L3VPN
474BNetwork requirements
CE 1 and CE 3 belong to VPN 1. CE 2 and CE 4 belong to VPN 2.
VPN 1 uses route target attribute 111:1. VPN 2 uses route target attribute 222:2. Users of different
VPNs cannot access each other.
EBGP is used to exchange VPN routing information between CE and PE.
