156
FEC Proto In/Out Label Interface/Out NHLFE
- StaticCR 20/30 Vlan2
3.2.1.2 Local -/- Vlan2
[SwitchC] display mpls lsp
FEC Proto In/Out Label Interface/Out NHLFE
- StaticCR 30/- -
[SwitchA] display mpls static-cr-lsp
Name LSR Type In/Out Label Out Interface State
static-cr-lsp-1 Ingress Null/20 Vlan1 Up
[SwitchB] display mpls static-cr-lsp
Name LSR Type In/Out Label Out Interface State
static-cr-lsp-1 Transit 20/30 Vlan2 Up
[SwitchC] display mpls static-cr-lsp
Name LSR Type In/Out Label Out Interface State
static-cr-lsp1 Egress 30/Null - Up
# Verify that Switch A has a static route entry with interface Tunnel 0 as the output interface.
[SwitchA] display ip routing-table
Destinations : 12 Routes : 12
Destination/Mask Proto Pre Cost NextHop Interface
0.0.0.0/32 Direct 0 0 127.0.0.1 InLoop0
1.1.1.1/32 Direct 0 0 127.0.0.1 InLoop0
2.1.1.0/24 Direct 0 0 2.1.1.1 Vlan1
2.1.1.0/32 Direct 0 0 2.1.1.1 Vlan1
2.1.1.1/32 Direct 0 0 127.0.0.1 InLoop0
2.1.1.255/32 Direct 0 0 2.1.1.1 Vlan1
2.2.2.2/32 IS_L1 15 10 2.1.1.2 Vlan1
100.1.2.0/24 Static 1 0 0.0.0.0 Tun0
3.3.3.3/32 IS_L1 15 20 2.1.1.2 Vlan1
6.1.1.0/24 Direct 0 0 6.1.1.1 Tun0
6.1.1.0/32 Direct 0 0 6.1.1.1 Tun0
6.1.1.1/32 Direct 0 0 127.0.0.1 InLoop0
6.1.1.255/32 Direct 0 0 6.1.1.1 Tun0
